A top sag rod connection at a sloped combined shape with a WT7x15 girt bracket. The assembly incorporates oversize holes with a 1/4 inch typical gap and a 1/4 inch fillet weld. Girt lines and column centerlines establish the critical setting dimensions for fabrication and field alignment.
SECTION ELEVATION 5" 1/4 4 1/4 3 SAG ROD SLOPED COMBINED SHAPE TOP SAG ROD CONNECTION WT7X15 GIRT BRACKET UNO GIRT LINE CL COL SECTION OVS HOLES NOTE 2 1/4" GAP TYP NOTE 1 CL COL NF NSFC 3" 1 1/2"
