A concrete wall meets an adjacent concrete wall at a building separation line, with scopes divided between Building J contract documents and Building K contract documents. A typical waterstop is installed within the joint as indicated on architectural drawings. The concrete wall designed by others references Building J structural drawings for reinforcing and additional information.
CONC WALL CONC WALL DESIGNED BY OTHERS. SEE BUILDING J STRUCTURAL DRAWINGS FOR REINFORCING AND ADDITIONAL INFORMATION DESIGN IN BUILDING K CONTRACT DOCUMENTS DESIGN IN BUILDING J CONTRACT DOCUMENTS TYPICAL WATERSTOP, SEE ARCH
