Metal deck bears perpendicularly across a steel beam supporting welded shear studs. Condition A requires a minimum one-half inch clearance from the stud to the metal deck flute when standard alignment cannot be attained. A one and one-half inch minimum clearance is specified, increasing to three inches minimum at drag beams.
MIN 1 1/2" METAL DECK METAL DECK CONDITION A 1/2" MIN DECK ┴ TO BEAM 1 1/2" MIN (3" MIN @ DRAG BEAMS), SEE CONDITION B WHEN CLEARANCE FROM STUD TO DECK FLUTE CANNOT BE ATTAINED
