A wide-flange column with intersecting wide-flange beams forms this steel deck corner assembly. Callouts designate the centerline of the column and reference plan locations for the framing members. Notes restrict attachments and bent plate splices within the designated protected zone of the structural members. Additional notes direct the builder to reference typical deck edge details for unshown information.
CL OF COLUMN WF BEAM REF. PLAN PLAN REF. NO ATTACHMENTS IN PROTECTED ZONE TYP. DECK CORNER NOTE: FOR INFORMATION NOT SHOWN REF. TYP. DECK EDGE. PROTECTED ZONE NO BENT PL SPLICE AT PROTECTED ZONE NO BENT PL SPLICE AT
