A glulam beam bears onto a glulam column connection supported by a three-quarter-inch bent plate with quarter-inch stiffener plates. Four half-inch diameter through bolts secure the bent plate assembly through the column. A two-by-four tenon on the column fits into a mortise in the end of the glulam beam. Simpson HTS straps are provided on each side of the column tying into the cross-laminated timber slab.
1" 8" 10" TYP. 2 1/2" 10" SECTION A-A A A GLULAM BEAM BEARING CONNECTION REF. PLAN CLT REF. PLAN SIMPSON HTS STRAP EACH SIDE OF COLUMN GLULAM COLUMN TYP. REF. PLAN EXTERIOR WALL FRAMING REF. PLAN 3/4" BENT PLATE 1/4" STIFFENER PL. PL3/8x2 1/2 TYP. (4) 1/2" DIA. THRU BOLTS 2x4 TENON ON COLUMN AND MORTISE IN END OF BEAM GLULAM BEAM
