A steel joist with a nailer held back 10 inches bears on a C12 channel ledger connected to a concrete wall panel. The concrete panel features two continuous number 4 reinforcing bars added without hooks at the inside face and tied to nailer strips. A gauge metal strap with pins ties the roof sheathing to the assembly.
GAUGE METAL STRAP AND PINS JOIST TIE ROOF SHEATHING STEEL JOIST WITH NAILER HELD BACK 10" TYP. THIS CONDITION JOIST SEAT AND STIFFENERS C12 CHANNEL LEDGER, SEE DETAIL CONC. PANEL ADD (2) #4 CONT. WITHOUT HOOKS TO REINF. AT INSIDE FACE. TIE TO NSA'S 5" 2 1/2" / 1 B4-S6.1
