Steel beams frame into a structural column through bolted moment connections. A hidden moment frame beam is shown shaded behind the connection elements for clarity. Shear tabs and bolted flange plates transfer the lateral loads and bending moments between the members. Diagonal stiffeners reinforce the column web at the beam flange locations.
STL. BEAM SEE PLAN STL. BEAM SEE PLAN MOMENT FRAME BM. SHOWN HIDDEN AND SHADED FOR CLARITY 11 S0.4 4 S0.9
