A horizontal truss connects to a vertical structural beam using a connection plate designated as plate t1. The plate is secured with bolted connections to the typical horizontal truss members, maintaining a typical maximum one-inch clearance from the centerline of the beam. A work point is established at the intersection of centerlines, with a three-sixteenths inch fillet weld indicated for the connection.
SECT A CL TYP 1" MAX, DETAIL A BM CONN PL "t1" HORIZ TRUSS, TYP CL BM WP (3/16) 3
