Single-plate shear tabs are configured for skewed steel beam framing. For skews less than or equal to 3-5/8 inches in 12 inches (or up to 17 degrees), a 3/8-inch beveled shear tab is provided at the contractor's option with a 1/4-inch fillet weld. For skews over 3-5/8 inches in 12 inches up to 7 inches in 12 inches (or between 17 and 30 degrees), a 1/2-inch beveled shear tab is used with a 1/4-inch fillet weld. High-strength bolts secure the supported member web to the plate, with standard edge distances of 3/4-inch and 2-1/2 inches indicated.
12 x ≤3 5/8 SKEW LESS THAN OR EQUAL TO 3 5/8 IN 12 3/4" 2 1/2" ANGLE ≤ 17° SKEW 3/8 1/4 BEVELED SHEAR TAB AT CONTRACTORS OPTION X 12 3 5/8 < x ≤7 SKEW OVER 3 5/8 IN 12 TO 7 IN 12 3/4" 2 1/2" "t" 17° < Ɵ ≤ 30° SKEW ANGLE 1/2 1/4 BEVELED SHEAR TAB X
