A structural steel connection detail shows steel beams framing into a central column with welded plates and headed shear studs. The connection incorporates a three-quarter-inch A572-50 plate welded with a three-quarter-inch fillet weld, featuring sixteen seven-eighths-inch by eight-inch headed studs spaced at four inches on center. A separate connection detail utilizes a one-quarter-inch A572-50 plate with sixteen seven-eighths-inch by eight-inch headed studs at four inches on center, combined with a six-bolt connection per detail 13 on sheet S52-00. Studs are aligned with studs beyond, and dimensions specify spacing of four inches and two inches across the plate layout.
4" 4" 4" 2" 4½" 4" 4" 4" 2" 2½" (6) BOLT CONN. PER 1/4" A572 -50 W/ (16) 7/8""x8" HEADED STUDS @ 4" O.C. GA. 13 S52-00 3/4 TYP. 3/4" A572 -50 W/ (104) 7/8""x8" HEADED STUDS @ 4" O.C. GA. - ALIGN W/ STUDS BEYOND
