Double curtain rebar configuration at the end of a concrete wall or door/window jamb. A second row of reinforcing bars is provided where required, with lap splices installed according to the schedule. Head bars include two number seven bars for openings up to twelve feet wide, and four number seven bars for openings up to sixteen feet eight inches wide, unless noted otherwise.
LAP SPLICE PER SCHEULDE END OF WALL OR JAMB BARS DOUBLE CURTAIN HEAD BARS DOUBLE CURTAIN PROVIDE 2-#7 FOR OPENINGS UP TO 12'-0" WIDE - 4-#7 FOR OPENINGS UP TO 16'-8" WIDE, UNO SECOND ROW OF BARS WHERE OCCURS
