Cold-formed metal stud partition wall bracing layouts illustrate required diagonal stud bracing configurations based on room dimensions and wall heights. A 10-foot by 10-foot room with a maximum wall height of 12 feet and 43 mils continuous track requires no bracing. Larger rooms utilize 362S125-43 studs for diagonal bracing positioned at specified offsets and intervals.
