A square base plate is centered around a hollow structural section column with four corner anchor bolts. A centered grout hole is provided with a size matching the anchor bolt hole size. A five-sixteenth inch or American Welding Society minimum weld connects the assembly per plan requirements. Edge distances measure two inches to equal spaces across the plate width.
PLAN OR AWS MIN GROUT HOLE ON BASE PLATE - SIZE OF HOLE SAME AS ANCHOR BOLT HOLE SIZE 5/16 2" EQ EQ 2" WIDTH SEE SCHED 1" SEE PLAN
