An existing concrete slab intersects an existing concrete shear wall at Level 3. A concrete shear wall overlay extends upward from the level, reinforced with number five U-bars that match and lap with the vertical reinforcing steel. Number four epoxy dowels measuring three feet in length are spaced at twelve inches on center with a three-inch embedment into the top of the overlay to tie into the assembly above. The top row of epoxy dowels is spaced at twelve inches.
W (E) CONC SLAB, TYP CONC SW OVERLAY (E) CONC SW 215 LEVEL 3 2'-0" #4x3'-0" @ 12" EPOXY DWLS W/ 3" EMBED #5 U BARS TO MATCH AND LAP W/ VERT REINF SPACE TOP ROW OF EPOXY DWLS AT 12"
