Concrete tilt-up panels feature cast-in embed plates for deck bearing located across a three-quarter inch panel joint. Embed plates are positioned per structural drawings C4 and C6 on sheet S702. Dimension X measures the distance from the panel edge to the embed, requiring relocation if dimension X drops below four inches to maintain minimum edge distance. Three equal spaces span the panel joint configuration.
(UNLESS DIM "X" IS LESS THAN 4") (SEE NOTE 1) (3) EQUAL SPACES 3/4" PANEL JOINT "X" CONC TILT-UP PANEL DECK BRG EMBED PL PER TYP / (C4 S702) EMBED PL PER TYP / (C6 S702) NOTE 1, IF EVEN DIM "X" IS LESS THAN 4" EMBED SHALL BE MOVED AWAY FROM PANEL EDGE TO MAINTAIN 4" MIN. TYP
