Concrete panel joints incorporate horizontal bars with hooked ends that extend into the jamb for the full width of the jamb and lap ties, alongside two continuous vertical bars at each end. Jamb reinforcing size and spacing are determined per schedule, with clearance to vertical bars coordinated accordingly. Panel configurations feature a maximum three-quarter-inch reveal located per architectural drawings.
PER SCHEDULE EQ. EQ. PER SCHEDULE 3/4" REVEAL (MAX.) SEE ARCH. DWGS FOR LOCATIONS CLEARANCE TO VERTICAL BARS SEE SCHEDULES 3/4" REVEAL (MAX.) SEE ARCH. DWGS FOR LOCATIONS SECTION HORIZONTAL BARS WITH HOOKED ENDS, OR EXTEND INTO JAMB FOR FULL WIDTH OF JAMB AND LAP TIES (2) VERT. BARS CONT. @ EACH END HORIZONTAL BARS WITH HOOKED ENDS, OR EXTEND INTO JAMB FOR FULL WIDTH OF JAMB AND LAP TIES NOTE: SEE SCHEDULE FOR JAMB REINFORCING. NOTE: SEE SCHEDULE FOR JAMB REINFORCING. N.T.S S202 14 PANEL JOINT DETAILS
