This structural detail provides the plan layout for a column base plate with four anchor bolts and a designated grout hole. The base plate dimensions for length and width are referenced to the schedule, with edge distances dimensioned at two inches and equal spacing between bolts. A separate grout hole is located on the base plate, sized identically to the anchor bolt hole. The column profile is indicated at the center with a one-inch clearance note referencing the structural plan.
PLAN GROUT HOLE ON BASE PLATE - SIZE OF HOLE SAME AS ANCHOR BOLT HOLE SIZE 2" EQ EQ 2" LENGTH SEE SCHED 2" EQ EQ 2" WIDTH SEE SCHED 1" SEE PLAN
