A single-story X-brace intersection features a one-quarter-inch gusset plate connected with three-quarter-inch typical erection bolts. The bracing members are positioned relative to the work point and centerline of brace per elevation. Fillet welds of one-quarter-inch size are typically specified at the gusset plate connections.
BRACE PER ELEVATION TYP TYP 2" 6" TYP 3" 3" 4" 4" 3 S331 3 S331 1/4" GUSSET PL CL BRACE 1/4 1/4 TYP Ø3/4" ERECTION BOLT TYP 1/4 1/4 WP BRACE PER ELEVATION TYP TYP 2" 6" TYP 3" 3" 4" 4" 3 S331 3 S331 1/4" GUSSET PL CL BRACE 1/4 1/4 TYP Ø3/4" ERECTION BOLT TYP 1/4 1/4 WP
