A pipe or conduit passes through a concrete slab on grade supported by firm undisturbed soil or compacted fill. The slab transitions to a thickened concrete profile around the penetration, providing a minimum six-inch depth clearance below the conduit and a twelve-inch horizontal width. Typical slab reinforcing is installed per the structural plans above the sub-base and around the penetration.
12" MIN 2" 6" 6" MIN TYPICAL SLAB REINFORCING SEE PLAN TYPICAL SLAB THICKNESS FIRM UNDISTURBED SOIL OR COMPACTED FILL PIPE OR CONDUIT 1 1 w I C Q A ' i. A id * \ b A □ b ■ /' id A ^ A Id b A A
