A two-and-one-half-inch deep joist bearing end connects to the top flange of a supporting steel beam using one-half-inch diameter erection bolts and a welded connection. The steel beam rests on a steel cap plate secured to the top of a steel column. Beam web stiffener plates are welded to each side of the beam web over the column support. A stabilizer plate is provided at the column connection with fillet welds.
JK1RMW13 STEEL CAP PLATE STEEL BEAM STEEL COLUMN 2.1/2" DEEP JOIST BRG END W/ 2-1/2"Ø ERECTION BOLTS STEEL DECK STABILIZER PLATE BEAM WEB STIFFENER PLATE EACH SIDE 3/16 TYP 1/8 2 1/8 2 TYP 1/4 TYP
