A steel wide flange member is detailed with plates attached per the schedule and connected with typical welds. The beam is designated per plan and referenced with note two. Plate widths are dimensioned across the bottom of the section.
STL WIDE FLG PER PLAN PL PER SCHED TYP W TYPICAL SECTION WIDTH PLATE L BM, NOTE 2
