An existing steel beam connects to an existing steel column using a double angle connection with a variable bolt quantity. A quarter-inch fillet weld is specified across three sides typically. The assembly occurs at both sides of the column per plan. Additional beams framing into the column are omitted for clarity.
(E) DOUBLE ANGLE BOLT QUANTITY VARIES (E) BEAM (E) COLUMN ORIENTATION VARIES DETAIL OCCURS AT BOTH SIDES REF. PLAN NOTE: ADDITIONAL BEAMS FRAMING INTO COL. NOT SHOWN FOR CLARITY. 1/4 (3) SIDES TYP. 1/4 1/4 1/4
