A wide-flange beam or channel connects to an HSS column using a shear tab welded to the column face and bolted to the supported member web. A cap plate is welded to the top of the HSS column with a one-quarter inch fillet weld. The number and size of bolts are sized per plan. Field welds are indicated with standard welding symbols.
WF BEAM OR CHANNEL TO J HSS COLUMN CONNECTION NO & SIZE OF BOLTS (SEE NOTE 3) HSS COLUMN WF BEAM OR CHANNEL (SEE PLAN) CAP PLATE AT TOP OF HSS COLUMN T&B 1/2" 1/4 M SHOWN ON PLAN THUS:
