The detail illustrates a cold-formed steel framing condition featuring 54 mil metal studs spaced at a maximum of 16 inches on center. A continuous plate measuring at least 6 inches by 54 mil is installed horizontally across the studs, spanning a minimum length of 3 bays. The continuous plate is secured to each metal stud using three #8 sheet metal screws.
Text on the drawing
2 1 ISOMETRIC DETAIL 54 MIL METAL STUDS @ 16"O/C MAX. EA. STUD (3) #8 S.M.S. @ 6" (MIN.)x54 MIL 3 BAYS) (MIN. LENGTH OF CONT PLATE TYPE A BTWN SUPPORTING STUDS (MIN. LENGTH OF 3 BAYS)
