Clear edge distance dimension 'A' and clear spacing dimension 'B' for spliced or lapped reinforcing bars. Bar diameter is designated as db, with minimum clear spacing governed by general note E.8. The layout establishes geometric parameters for concrete reinforcement placement.
BAR SPACING DIAGRAM SPLICE OR LAPPING BAR A. B. LEGEND: CLEAR EDGE DISTANCE CLEAR SPACING OF SPLICED OR LAPPED BARS (SEE GEN NOTE 'E.8' FOR MIN CLEAR SPACING) db = BAR ⌀ A B A db B A
