This cold-formed steel rough opening assembly consists of a built-up header supported by vertical jamb studs and a sill member at the bottom. Cripple studs span between the top track and the built-up header, as well as between the sill and the bottom track. A trim track fastens to the web with number eight screws at each flange. Clips connect the sill member to the jamb studs, while standard top and bottom tracks anchor the framing assembly.
TOP TRACK CRIPPLE STUD BUILT-UP HDR TRIM TRACK @ WEB,#8 @ EA FLANGE BOTTOM TRACK, TYP. SILL CRIPPLE STUD JAMB STUD CLIP
