Concrete wall reinforcing layouts for small wall sections and corners with double layer reinforcing bars. Sections up to two feet wide utilize number three ties spaced at eight inches on center, while sections from two to four feet wide incorporate typical wall reinforcing. Corner details show the lap lengths and placement for separate corner bars which are optional. These details apply in both horizontal and vertical directions as noted on the drawing.
TYP. WALL REINFORCING #3 TIES @ 8'' o.c. CORNER DETAILS BARS IN SMALL SECTION UP TO 2'-0" 2'-0" TO 4'-0" 1' - 6" 1' - 0" 1' - 0" SEPARATE CORNER BARS OPTIONAL NOTE: ABOVE DETAILS APPLY IN BOTH HORIZONTAL AND VERTICAL DIRECTIONS. SEPARATE CORNER BARS OPTIONAL 1'-6" 1'-6"
