A hollow structural section roof screen post bears on a continuous glulam beam supported by a structural tee bracket connection. A kicker brace ties back to the post using bolted connections for lateral stability. Screws secure the glulam connection per plan details. Additional information for the kicker brace and connection configuration is referenced on supplemental drawings.
C.L. SCREEN POST D ROOF SCREEN POST AT CONT. GLB ROOF SCREEN GLB E.S. PER PLAN ROOF S.A.D. CONT. GLB PER PLAN TYP. GLB CONN. W/ ADDED SCREWS PER 1A/s-806 CONT. GLB PER PLAN SEE A & B FOR INFO NOT SHOWN SEE DETAIL A FOR KICKER BRACE INFO. WT BRACKET PER A 1
