A wide flange beam connects to studs and the solid wall via a gravity connection detailed on sheet S6.21. An architectural drift track is included to allow for vertical building deflection and seismic drifts. The framing assembly coordinates structural steel elements with stud wall construction at the building perimeter.
SEE ARCH DRIFT TRACK CONNECTION TO ALLOW VERTICAL BUILDING DEFLECTION AND SEISMIC DRIFTS NOTED ON THE GSN WIDE FLANGE BEAM GRAVITY CONN TO STUDS AND BEAM / (1 S6.21)
