Two adjacent concrete tilt-up panels are separated by a vertical panel joint of width X. Each panel incorporates an embed plate for deck bearing, specified per detail 1 on sheet SE702. The deck bearing line aligns with the embed plates across the face of the panels. The panel joint configuration is referenced to the architectural drawings for further specification.
