Cold-formed metal framing jamb stud base and track anchorage conditions for interior and exterior applications. The assembly features jamb studs per schedule secured to tracks using self-drilling sheet metal screws, with anchor bolts, powder-actuated fasteners, and screw anchors fastening the base tracks to the substrate. Additional clips, angles such as L2x2x97, and multiple stud configurations are detailed for wide door openings and exterior curbs.
L2x2x97 MILS x 3" (4) #12 SMS TRACK PAF #8 SMS EA SIDE JAMB STUD PER SCHED #8 SMS ES TRACK PAF #8 SMS ES TRACK PAF ES JAMB B A C AT DOOR < 4'-0" WIDE AT DOOR > 4'-0" WIDE TYP 4" 2 1/2" 2 1/2" 4" Í"ø x 4" SCREW AB PER 3 S1.4 ___________ JAMB STUDS PER SCHED JAMB STUDS PER SCHED FOR INFORMATION NOT NOTED SEE 14 S1.4 ___________ 14 S1.4 ___________ (INTERIOR ONLY) (INTERIOR ONLY) (4) #8 SMS TRACK #8 SMS EA SIDE E AT CURB CLIP PER ES AT OPNGS > 6'-0" TYP 14 S1.4 ___________ (EXTERIOR ONLY) B TRACK (2) Ï"ø SCREW ANCHORS (1) ES #8 SMS EA SIDE D TYP CLIP PER ES AT OPNGS > 6'-0" TYP 14 S1.4 ___________ (EXTERIOR ONLY) B (1) Ï"ø SCREW ANCHOR ES JAMB STUD (2) STUDS PER SCHED (3) STUDS WHERE OCCURS PER SCHED 6" 15 S1.1
