A wide flange beam connects to a hollow structural section column using a three-eighths-inch full-height stiffener plate on both sides secured with an erection bolt. A quarter-inch cap plate is welded to the HSS column. A five-sixteenths-inch full-height stiffener plate is centered on the HSS column. Fillet welds of one-quarter-inch size are specified on three sides typically.
3 TIMES BEAM WALL THK. FULL HT. STIFF. PLATE 3/8 BOTH SIDES HSS W/ ERECTION BOLT FULL HT. STIFF. PLATE 5/16 CTR. ON HSS SECTION A-A WIDE FLANGE BEAM CONDITION 5B ELEVATION A A BEAM END WHERE OCCURS HSS BEAM MAX. 1/2" 3" 1/4 (3) SIDES, TYP. 1/4 TYP. 3 SIDES 1" 1/4" CAP PLATE
