A new steel beam frames into the weak-way axis of an existing wide flange column using a bolted shear tab welded to a transfer plate assembly. The connection utilizes existing and new half-inch stiffener plates welded to the column flanges with complete joint penetration welds and demand critical requirements. A slot is cut through the stiffener plate with a seven-sixteenth-inch drilled hole at each end, maintaining a half-inch maximum clearance. The new steel beam is sized per plan and bolted to the connection plate with four structural bolts.
(E) WF COL. (E) STIFF. PL1/2", V.I.F. WF TO WEAK-WAY WF COLUMN CONN. PER DETAIL 8/- (N) STEEL BEAM PER PLAN DRILL 7/16"Ø HOLE AT END OF SLOT V.I.F. 2" TYP. SECTION A-A A A CJP, DC, TYP. (3/8) 1/2" MAX. (N) STIFF. PL1/2" TYP. 2"
