This elevation detail shows a structural steel hollow structural section column supported by a base plate anchored within a concrete pile cap blockout. Continuous slab reinforcement and two number five minimum trim bars frame the blockout perimeter with typical six-inch minimum clearances. The slab reinforcement and top of pile cap are positioned as detailed in the structural plans.
- ELEVATION AT HSS COLUMN E SEE SCHED. BASE PL. BLOCKOUT 1'-0" MIN. TYP. MIN. 6" TYP. 6" MIN. 6" FOR ADDITIONAL INFORMATION NOT SHOWN SEE A/- SIM. AROUND COL. MIN. BOTTOM OF PILECAP SEE PLAN 2-#5 MIN. TRIM BARS CONT. SLAB REINF. OR TOP OF SLAB SLAB REINF., SEE PLAN SEE PLAN TOP OF PILECAP, SEE PLAN TS COLUMN
