A curved W12x beam frames into a hollow structural section column using a one-half inch thick knife plate connection. The knife plate slots into the structural tee and is secured with three bolts detailed per schedule. A continuous one-quarter inch fillet weld attaches the connection assembly. Stiffener plates sized per plan reinforce the column web at the connection location.
HSS COL 1/2" D 1/2" THK KNIFE PL CONNECTION PER / 7 S-601 1/2" 1 1/2" 3" 1 1/2" HSS COL W18x PER PLAN W12x CURVED BEAM PER PLAN 1 1/2" 1 15/16" 1/2" MAX 1 3/4" 1 3/4" BOLTS PER / 7 S-601 STIFFENER PER / 3 S-600 1/4
