An elevator pit structural framing assembly with wide-flange beams sized per plan supported by vertical hangers sized per plan. The framing connects at a level of zero feet zero inches down to an elevator pit at minus eight feet seven inches. Structural on-grade slab deck is provided per plan with typical detail references coordinating the connections.
LEVEL 1 0'-0" 2 -8'-7" ELEVATOR PIT HGR PER PLAN, TYP WF BM PER PLAN, TYP SOSD PER PLAN CL HGR CL BM 6 1/4" 15 S6.01 S6.01 20 TYP S6.01 12 S6.01 17 CL HGR CL BM WP WP CL BM
