An hollow structural section post extends through the roof assembly and is supported by a wide-flange beam sized per plan. Diagonal braces made of L3x3x1/4 angles run on both sides of the HSS post, tied with top and bottom L3x3x1/4 angles. Three-inch-long hollow structural section spacers matching the post size are placed at each end of the double angles. A continuous quarter-inch bent plate is welded around the HSS post with field fillet welds. The roof deck bears on the wide-flange beam with a coped angle connecting to the joist per typical details.
ARCH. SEE 3/16 2 3/16 TYP. 3/16 1 1/2 TYP. 3/16 1 1/2 TYP. COPE ANGLE AND CONNECT TO JOIST PER TYPICAL DETAIL --/---- HSS POST - SEE PLAN FOR SIZE AND SPACING 1/4" BENT PLATE x REQ'D x CONT. L3 x 3 x 1/4 BOTH SIDES OF HSS POST L3 x 3 x 1/4 DIAGONAL BRACE (TYP.) 3" LONG, HSS SPACER MATCH SIZE OF POST PLACE AT EACH END OF DOUBLE ANGLE TYP. TOP AND BOTTOM L3 x 3 x 1/4 BOTH SIDES OF HSS POST W BEAM - SEE PLAN 4" REQ'D ROOF DECK - SEE SCHEDULE FOR SIZE AND ATTACHMENT
