Structural · S-VVXMB

Perimeter Detail at Level 2 Soffit and Curtain Wall

Materials

Timber / Wood Glass / Glazing

Elements

Beams Walls Curtain Walls Ceilings Floors / Slabs Arches Bracing Connections / Plates

Connections

Beam-to-Beam

About this detail

Perimeter soffit and curtain wall connection at the level two floor slab edge. The assembly incorporates steel beams supporting a concrete slab on metal deck, with a gravity connection at the slab edge and an angle section measuring L4x4x1/4 at five feet on center maximum. Steel studs and their structural connections are provided by the supplier, with all studs gravity-supported at level two and maintaining a one-inch plus-or-minus gap. The top of the curtain wall is braced by a stud assembly designed to accommodate vertical and lateral deflections per the general structural notes. Glazing and finishes are coordinated per the architectural drawings, with beam-to-beam connections omitted for clarity.
