A davit socket pedestal mounts onto a steel plate or beam flange above the top of roofing, with the socket design provided by others. Additional reinforcement consisting of four number five bars at six feet zero inches each way is placed in concrete filled decks, with standard hooks provided at the slab edge where applicable. The offset distance varies with a one foot eight inch vertical dimension to the socket base. Welds are specified with a three-eighths inch size typically.
A DAVIT SOCKET PEDESTAL TYPICAL AT ALL DAVIT SOCKETS AT CONC FILLED DECKS (ADD 4#5x6'-0" EW. PROVIDE STANDARD HOOK AT SLAB EDGE WHERE OCCURS) PL OR BEAM FLANGE TOP OF ROOFING DAVIT SOCKET DESIGN BY OTHERS DAVIT SUPPORT OFFSET AT COLUMN E VARIES 1'-8" 3/8 TYP
