A buckling-restrained brace connects to a ten-inch extra-strong pipe column using welded pipe casings and internal kerf plates. Three-quarter-inch Grade 50 kerf plates insert into the ends of the pipe braces and are secured with three-sixteenth-inch typical cap plates. The connection details include five-sixteenth-inch and one-quarter-inch fillet welds alongside complete joint penetration welds at the central work point.
3" 3" 1" WORK POINT KERF PL 3/4" x REQD (GR50), TYP 3 LOCATIONS CORE BRACE BRB WELDED CONNECTION W/ 10" PIPE CASING PIPE BRACE, SEE PLAN 10XS PIPE COLUMN 5/16 5/16 TYP CJP 5/16 10" 5/16 10" 1/4 20" 3/16" CAP PL TYP 9 S-301
