An exterior wall section details the connection of a hollow structural section girt to a structural column via a girt bracket. A continuous plate measuring one-quarter inch by nine inches is secured beneath the girt with three-sixteenth-inch fillet welds spaced at two feet twelve inches on center. The hollow structural section girt is coped as required for bolted connections and receives a support angle for the exterior panel or louver. A concrete masonry unit wall positioned below provides support and interfaces with a structural sub-joint per architectural drawings. The structural column is sized per schedule and aligns with the building grid.
L GRID 2-12 GIRT BRACKET PER S-560 GRID 8" CONT PL1/4X9 3/16 2-12 TRLNT PANEL OR LOUVER PER ARCH DWG A-201 & A-202 2'-10" COL PER SCHED SSJ PER ARCH DWG A-441 - A-444 CMU WALL PER PLAN HSS GIRT PER EL COPE AS REQD FOR BOLT CONN SUPT ANGLE BY TRLNT PANEL OR LOUVER DSGNR, COPE HORIZ LEG AS REQD
