A non-bearing concrete tilt-up panel intersects a vertical bearing tilt-up wall panel with a minimum 2-inch clearance. Both panels contain vertical and horizontal concrete tilt-up panel reinforcement as detailed in the structural notes. The connection detail indicates standard bearing conditions and references secondary sheets for panel-to-panel connection requirements.
VERT CONC TILT-UP PANEL REINF HORIZ CONC TILT-UP PANEL REINF OUTSIDE FACE OF PANEL TYP BEARING TILT-UP PANEL, FOR TYP PANEL TO PANEL CONN, SEE 2" MIN NON-BEARING TILT PANEL, FOR REINF SEE VERT CONC TILT-UP PANEL REINF HORIZ CONC TILT- UP PANEL REINF / (- ---)
