This structural detail outlines the manufacturing tolerances and geometric requirements for steel side plates in timber rivet connections. Hole diameters range from 17/64 inch minimum to 18/64 inch maximum, with location tolerances limited to 1/8 inch maximum in any direction. All dimensions apply prior to galvanizing. The end edge distance is specified as 1/2 inch minimum, and the wide face of rivets must be oriented parallel to the wood grain regardless of plate orientation.
MIN MIN. MIN. es = 1/2" MIN. es = 1/2" GRAIN NOTES: 1. HOLE DIAMETER: 17/64" MINIMUM TO 18/64" MAXIMUM. 2. TOLENRENCES IN LOCATION OF HOLES: 1/8" MAXIMUM IN ANY DIRECTION. 3. ALL DIMENSIONS ARE PRIOR TO GALVANIZING IN INCHES. 4. Sp AND Sq ARE DEFINES IN 13.3. 5. es IS THE END EDGE DISTANCE AS DEFINED BY THE STEEL. 6. ORIENT WIDE FACE OF RIVETS PARALLEL TO GRAIN, REGARDLESS OF PLATE ORIENTATION. STEEL SIDE PLATE DIMENSIONS Detail Courtesy American Wood Council, Leesburg, VA 12/10/2015 4:53:25 PM C:\Projects\Glenn County Willows Courthouse\Revit\eao_WILLOWSCOURT_RS15_20141008.rvt 17 MANUFACTURING TOLERENCES FOR RIVETS & STEEL SIDE PLATES FOR TIMBER RIVET CONN.
