A diagonal brace frames into the midspan of a wide flange beam. The connection incorporates a diagonal brace member meeting the beam web and flange at a designated work point. The horizontal legs of the connecting angles are mitered, and the vertical legs below are trimmed with a one-inch maximum clearance dimension. Five-sixteenths inch fillet welds secure the connection assembly.
1" MAX. MITER HORIZONTAL LEG OF ANGLE TRIM VERTICAL LEGS OF ANGLE BELOW WORK POINT MIDSPAN OF BEAM DIAGONAL BRACE REF. PLAN WF BEAM REF. PLAN 5/16 4 5/16 PLAN DETAIL
