A welded transition connection for a steel column executes flange and web transitions according to specified type A column flange and web transition details. A vertical dimension of four feet six inches is maintained to the top of the structural steel beam below unless noted otherwise.
4'-6" TO TOS OF BM BELOW, UNO STL COL FLANGE WELD PER "TYPE A BF COL FLANGE AND WEB TRANSITIONS" DETAIL FLANGE WELD PER "TYPE A BF COL FLANGE AND WEB TRANSITIONS" DETAIL FLANGE TRANSITION PER DETAIL B
