Structural · S-VB6N8

Typical Deck Bearing Angles at Steel Column

Materials

Steel

Elements

Columns Beams Decks Bracing

Connections

Bracing Connection

About this detail

Bearing angles and diagonal bracing frame into a steel column and support steel beams or joists. Steel angles sized L3x3x1/4 serve as typical braces connected with three-sixteenth-inch fillet welds. Steel shims, which may consist of sections of angle, channel, or steel tube, are provided where required. Similar conditions exist at the building perimeter and corners.
