Cold-formed steel stud framing connected to bottom and top tracks using number ten Tek screws on each side. A maximum gap of one-eighth inch is maintained between the stud and track. Screws are spaced at a minimum of twelve inches typical along the connection.
12" MIN #10 TEK SCREW ES, TYP SCREWED OPTION 12" MIN 1/8" MAX GAP BTWN STUD AND TRACK, TYP
