Longitudinal reinforcement must be arranged to avoid the opening. The pipe is insulated with one inch of foam and located within the middle two-thirds of the beam width. The total beam width is designated as W, with the outer sixth sections at each side and the central two-thirds section dimensioned accordingly.
