This connection details a structural steel truss bearing on a structural wall with internal stiffener plates. Sixteen one-inch diameter anchor rods secure the assembly through bearing plates. Diagonal members frame into the chord alignment with centerlines referenced to the grid. A general note directs attention to the typical diagonal to chord connection detail.
℄ DIAG ℄ DIAG GRID SEE ELEVATION TRUSS STIFF PL PL (16) 1" DIA AR SW ℄ CHORD NOTES: 1. SEE "TYPICAL DIAGONAL TO CHORD CONNECTION" DETAIL. 2 17 TYPICAL TRUSS TO WALL CONNECTION
