The drawing illustrates a reinforced concrete foundation assembly with cast-in-place concrete walls, a slab with a sloped topping, and supporting piles shown extending beyond. Key elements include 15M and 25M reinforcing bars, a 50mm mud slab below the foundation, thermal insulation extending from the underside of the slab, and specific elevations and dimensions for structural clarity.
Text on the drawing
SLOPE SLOPE T.O MAIN FLOOR 100.00 VARIES FROM 20 TO 200 AT DRAIN, SEE PLUMBING DRAWINGS CLR 40 CLR 20 40 250 300 25M@200 EW T&B 15M@250 EW EF 15M@250 EW EF 5 S-MB-5.04 PILE BEYOND PILE BEYOND TYP 100 640 390 TOC SEE PLAN 500 MIN TO TERMINATOR EL = 98.077 TO TERMINATOR EL = 98.224 156 150 TO TERMINATOR EL = 98.294 TO TERMINATOR EL = 98.073 TOC EL 98.45 50 MUD SLAB 50 MUD SLAB EXTENT OF INSULATION FROM U/S OF SLAB , TYP TYP 300 ld 1200 300 1200 TYP 300 204 150 300 150
